Caracteristici generale
Numar Porturi
8x RJ45
1x RJ45 (uplink)
1x SFP (uplink)
Viteza Transfer LAN
1 Gbps
Tehnologie de cablare
RJ45 Base-T
Base-X
Standarde
IEEE 802.3at, IEEE 802.3af, IEEE 802.1ak, IEEE 802.1as, IEEE 802.1Qat, IEEE 802.1Qav, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1ab (LLDP), IEEE 802.3ad (LACP)
Securitate
TLS 1.2, SSL 3.0
Rutare IP
IPv4: 512
IPv6: 128
Caracteristici speciale
IGMP support, AVB, PoE timer, MIB support, RSPAN, LLDP-MED, policy based routing, PTP, STP support, MTP, RSTP, BPDU, STRG, Root Guard, GVRP, GMRP, LACP support, DHCP snooping, DAI, IP source guard, DHCP relay, LLDP support, AAA, sFlow, PIM, MVRP, LACP, LAG, Private VLAN, VLAN support, DHCP server, QoS, DoS attack prevention, 16MB packet buffer, fanless
Conectori
1x USB-A
1x USB-C Console
1x RJ-45 Management
Procesor
ARM A9 1.25 Ghz 32-Bit
Forwarding rate
14.88 Mpps
Protocoale de rutare
IGMP, IGMPv2, IGMPv3, MLDv2, static IPv4 routing, static IPv6 routing, RIP, PIM-SM, PIM-DM, PIM-SSM
Remote Management Protocol
HTTPS, CLI, Telnet, SSH, SNMP, RADIUS, TACACS+, RMON 1, RMON 2, RMON 9, RMON 3, SNMP 1, SNMP 2, SNMP 3
Disipare caldura
Cu PoE: 451.5 Btu/hr
Fara PoE: 33.73 Btu/hr
Alimentare
Adaptor alimentare extern, 130 W
Putere consumata (W)
Cu PoE Max: 132. 25 W
Fara PoE Max: 9.88 W
Dimensiuni
210 x 140 x 40 mm
Continut pachet
Switch
Alimentator
Cablu alimentare
Kit de montare perete
Ghid de instalare rapidă
